P/N | Freq. Range | I.L. | VSWR | Limiting Level | Power Handling | Connector | Package |
GHz | dB Max | Max | dB Min. | W | mm | ||
KLT-0.5-2G-2W-SF | 0.5-2 | 0.6 | 1.4 | 20 | 2 | SMA-F | K01 |
KLT-1-4G-2W-SF | 1~4 | 0.8 | 1.5 | 20 | 2 | SMA-F | K01 |
KLT-2-8G-2W-SF | 2~8 | 1 | 1.6 | 20 | 2 | SMA-F | K01 |
KLT-8-12G-2W-SF | 8~12 | 1.5 | 1.8 | 20 | 2 | SMA-F | K01 |
KLT-6-18G-2W-SF | 6~18 | 2 | 2 | 20 | 2 | SMA-F | K01 |
KLT-0.45-0.65G-10W-SF | 0.45-0.65 | 0.6 | 1.2 | 20 | 10 | SMA-F | K02 |
KLT-1.2-1.4G-10W-SF | 1.2-1.4 | 0.8 | 1.3 | 20 | 10 | SMA-F | K02 |
KLT-3.1-3.4G-10W-SF | 3.1-3.4 | 1 | 1.4 | 20 | 10 | SMA-F | K02 |
KLT-5.2-5.8G-10W-SF | 5.2-5.8 | 1.2 | 1.5 | 20 | 10 | SMA-F | K02 |
KLT-0.45-0.65G-100W-SF | 0.45-0.65 | 0.6 | 1.2 | 20 | 100 | SMA-F | K03 |
KLT-1.2-1.4G-100W-SF | 1.2-1.4 | 0.8 | 1.3 | 20 | 100 | SMA-F | K03 |
KLT-3.1-3.4G-100W-SF | 3.1-3.4 | 1 | 1.4 | 20 | 100 | SMA-F | K03 |
KLT-5.2-5.8G-80W-SF | 5.2-5.8 | 1.2 | 1.5 | 20 | 80 | SMA-F | K03 |
